Motor Specifications

Stator Diameter: 40 mm
Stator Thickness: 25 mm
No. of Stator Arms: 12
Magnet Poles: 10
Motor Wind: 4+3 Turn Delta
Motor Wire: 2-Strand 1.0 mm
Motor Kv: 1100KV RPM/Volt
No-Load Current (IO/10v): 4.19 Amps
Motor Resistance (RM): 0.006 Ohms
Max Continuous Current: 100 Amp
Max Continuous Power: 2400 Watt
Weight: 350 Grams
Outside Diameter: 50.8 mm
Shaft Diameter: 6 mm
Body Length: 54.5 mm
Overall Shaft Length: 90 mm
Max Lipo Cell: 6s
Peak Continuous Current: 130 Amps (5 seconds)
Peak Continuous Power: 2920 Watts (5 seconds)
Motor Timing: 5deg
Drive Frequency: 8kHz~32khz
