THETA RAZOR-T1B NFC HV Standard Brushless Tail Servo 550-800 size (black color)

THETA RAZOR-T1 Brushless HV Servo with NFC

NFC programmable brushless HV servo in the 40 mm standard size.
The application range of the servo is versatile from helicopter tail rotor servo from the 550 size up to the 800 size, as a throttle servo, rudder servo in shipbuilding, large aircraft and in a variety of different RC Cars.
Due to the SANWA SSR compatibility, the advantages of Sanwa Super Response transmission can be used in the RC car sector.

THETA RAZOR-T1 Brushless HV Servo with NFC

Specifications
---------------------------------------
NFC programmable via Android mobile phone app

Motor: Brushless
Operating Voltage: 5V bis 8.4V

with max. 2.6A current consumption:
- Speed at 5V: 0.062 sec/60°
- Speed at 6V: 0.054 sec/60°
- Speed at 7.4V: 0.047 sec/60°
- Speed at 8.4V: 0.042 sec/60°

- Torque at 5V: 17 kg/cm
- Torque at 6V: 18 kg/cm
- Torque at 7.4V: 19 kg/cm
- Torque at 8.4V: 20 kg/cm

with max. 5A current consumption:
- Speed at 5V: 0.058 sec/60°
- Speed at 6V: 0.051 sec/60°
- Speed at 7.4V: 0.046 sec/60°
- Speed at 8.4V: 0.039 sec/60°

- Torque at 5V: 20 kg/cm
- Torque at 6V: 24 kg/cm
- Torque at 7.4V: 27 kg/cm
- Torque at 8.4V: 30 kg/cm

Weight: 73g
Dimensions (mm): 40x20x38mm
Neutral pulse (factory-made): 760µs
Neutral pulse (optional per App): 1520µs
Working Frequency: 50–1000Hz
Output toothing: 25T Ø5.9mm (Nexspor, Futaba, Align, BK, Savöx usw.)
